Language Frontend and the Lexer

There are many software tools that process some kind of programming language. Compilers and interpreters are perhaps the most obvious, but also program analysis tools (e.g. Facebook Infer, GitHub CodeQL, Google’s Go Vet, Amazon CodeGuru), documentation generators (e.g. Doxygen, Javadoc). In fact, any software that has to read some kind of non-trivial configuration file (e.g. JSON, XML) needs to be able to process a formal language from a textual input.

Typically, the part of the software that is responsible for reading the text and constructing some internal representation of its structure is called a frontend. There is no one way to organise a front-end but, in practice, most frontends adopt a certain architecture which makes this complicated task a bit easier.

The aim of this lecture is to illustrate this architecture and its first component using our Microbrew interpreter frontend as an example.

The Microbrew Language

Microbrew, or the Little Bristol Rewriting language, is an extremely simple, yet Turing powerful programming language (the meaning of this latter term will become clear in the third part of the course), created this year for PLC. The language is based on first-order term rewriting, that is, computation proceeds by rewriting a function call using the definition of the function.

The Microbrew interpreter provides a Read Eval Print Loop (REPL) in which you can define functions and evaluate expressions.

Functions can be defined using the keyword def and giving an equation that, in functional programming style, describes the behaviour of the function over a given shape of input. For example, the following clauses define the first and second projection functions which, given a pair of arguments, returns the first or second one, respectively.

  > def Fst(x,y) = x
  > def Snd(x,y) = y

The equations consist of a function call on the left, then an equals symbol, then an expression on the right constructed from function calls and variables. Function symbols start with an uppercase letter and variables (function parameters) start with a lowercase letter.

Expressions can be evaluated simply by writing them at the REPL:

  > Fst(Foo(),Bar())
  Foo()

The system matches the expression Fst(Foo(),Bar()) with the first function clause above and replaces it by the body of the function (the expression on the RHS of the equals symbol), i.e. x, but with formal parameters appropriately replaced by actual parameters.

And that’s it. There are no datatypes in Microbrew, no numbers, no strings, no lists, arrays or dictionaries.

However, all of these datatypes can, in priciple, be simulated using uninterpreted function symbols (UF). By UF I mean function names that we have not given any defining equations for. If we ask the interpreter to evaluate a call of an UF, then no computation will occur (except possibly in evaluating the arguments to the function call) because there are no defining equations for the function. For example, continuing the current REPL session:

  > Who(Fst(Foo(),Bar()))
  Who(Foo())

Here, the interpreter is able to evaluate the call to Fst because we have a defining equation, but not the call to Who because we don’t. Incidentally, Foo() and Bar() are also examples of calls to UF.

We can use UF like constructors for datatypes (in the sense of functional programming). For example, although there are no numbers in Microbrew, we can encode the natural numbers using two UF, say Z for “zero” and S for “successor” (or “plus-1”). The idea is that the number n will be encoded by n-applications of the successor to zero. E.g. the number 0 will be encoded by zero applications of S to Z():

  > Z()
  Z()

And the number 3 will be encoded by three applications of S to Z():

  > S(S(S(Z())))
  S(S(S(Z())))

Using this encoding it is straightforward to define addition on natural numbers:

  > def Add(Z(),y) = y
  > def Add(S(x),y) = S(Add(x,y))

The first equation says that, when adding zero to any number y, the result is just y. The second says that, when adding a number of shape S(x), i.e. the successor of some other number x, to some number y, the result can be obtained by recursively adding x and y and then adding one more successor on top.

This is a standard recursive definition of addition, but I guess you may not be familiar with unary encodings of natural numbers, so you will either have to think about it for a while or just take my word for it. Anyway, it must work because when we add 2 and 2 we get 4:

  > Add(S(S(Z())),S(S(Z())))
  S(S(S(S(Z()))))

Multiplication follows a similar pattern:

  > def Mult(Z(),y) = Z()
  > def Mult(S(x),y) = Add(y,Mult(x,y))

  > Mult(S(S(Z())),S(S(S(Z()))))
  S(S(S(S(S(S(Z()))))))

Similarly you could choose two UF symbols, say T and F, and use T() and F() to represent Booleans, and define all the usual Boolean functions on them. You could choose UF symbols C and N to represent lists, with C(x,xs) for the cons of x and xs and N() for the empty list, e.g. the list consisting of the first three natural numbers would be written C(Z(),C(S(Z()),C(S(S(Z())),N()))).

Microbrew Formal Syntax

What you can build on top of this language (i.e. it’s expressive power - see part 3 of this unit) is not important to us now, the important thing is that the syntax of the language is extremely simple.

Grammatical Structure

The following is an LL(1) grammar for the syntax of Microbrew:

\[\begin{array}{rcl} \nt{Cmd} &\Coloneqq& \tm{\$}\\[2mm] &\mid& \nt{Exp}\ \tm{\$}\\[2mm] &\mid& \tm{def}\ \tm{ident}\ \tm{(}\ \nt{ExpList}\ \tm{)}\ \tm{=}\ \nt{Exp}\ \tm{\$}\\[4mm] \nt{Exp} &\Coloneqq& \tm{var} \\[2mm] &\mid& \tm{ident}\ \tm{(}\ \nt{ExpList}\ \tm{)}\\[4mm] \nt{ExpList} &\Coloneqq& \epsilon\\[2mm] &\mid& \nt{Exp}\ \nt{ExpList'}\\[4mm] \nt{ExpList'} &\Coloneqq& \epsilon\\[2mm] &\mid& \tm{,}\ \nt{Exp}\ \nt{ExpList'}\\[4mm] \end{array}\]

The distinguished starting nonterminal is $\nt{Cmd}$. The grammar is formed over eight terminal symbols:

\[\tm{var} \qquad \tm{ident} \qquad \tm{(} \qquad \tm{)} \qquad \tm{,} \qquad \tm{def} \qquad \tm{=} \qquad \tm{\$}\]

The terminal symbol $\tm{var}$ stands for variables (function parameters) and the terminal symbol $\tm{ident}$ stands for function names (IDENTifiers). The terminal symbol $\tm{$}$ is used as a marker to represent the end of the input string. Intuitively, the nonterminals can be thought of as follows:

$\nt{Exp}$ is the nonterminal that describes Microbrew expressions, it derives strings of terminal symbols such as:

\[\begin{array}{l} \tm{var}\\ \tm{ident}(\tm{var})\\ \tm{ident}(\tm{ident}(),\tm{ident}()) \end{array}\]

$\nt{ExpList}$ is the nonterminal that describes possibly empty, comma-separated lists of expressions, which are used to describe function parameters and the arguments at call sites. An example is:

\[\tm{var},\tm{ident}(\tm{var}),\tm{ident}(\tm{ident}(),\tm{ident}())\]

$\nt{Cmd}$ is the nonterminal that describes REPL commands, which can either simply be an expression, as above, or the definition of a new function equation, followed by the end-of-input marker, such as:

\[\tm{def}\ \tm{ident}(\tm{ident}(\tm{var}),\tm{var})\ \tm{=}\ \tm{ident}(\tm{ident}(\tm{var},\tm{var}))\ \$\]

Lexical Structure

You might be surprised that $\tm{var}$ and $\tm{ident}$ are terminal symbols and not nonterminals that derive every possible variable and identifier name respectively. However, this is actually very common in the definition of programming languages. It represents a certain level of abstraction: as far as the language grammar is concerned, variables and identifiers are abstract, black-box entities. The grammar can’t distinguish different identifiers apart - Z, S, Add and so on all appear to the grammar simply as a single terminal symbol $\tm{ident}$, though it can distinguish variables from identifiers since they are separate terminal symbols.

There are two good reasons for this.

The first is that there is some conceptual advantage to reasoning about a programming language at this higher level of abstraction. Typically, to determine if a given string really is a valid program in some programming language, there is simply no need to distinguish between identifiers. If there is some structure in the language that can contain an identifier Foo, then the structure does not become syntactically invalid by replacing Foo by Bar. For example, the syntactically valid Java class definition class Foo{} remains valid when replacing Foo by Bar to obtain class Bar{}.
The second reason is that there is usually a lot of overlap between the structure of program identifiers (or variables) and program keywords. Trying to tease out this overlap in an LL(1) grammar, although it may be possible, will usually be quite painful. For example, consider the C-language keyword for and the C-language identifier fortitude. A grammar that operates character-by-character (i.e. where the terminal symbols are just individual characters) would need to bake in a bunch of rules that factor out the common prefix for. A similar clash occurs in Microbrew between the keyword def and variable names like definitely.

So for these reasons the Microbrew grammar understands all identifiers simply as the terminal symbol $\tm{ident}$ and all variables simply as the terminal symbol $\tm{var}$. Of course, a Microcode program is actually written as text, a string, so at some point someone needs to say which sequences of characters actually constitute a valid identifer and which constitute a valid variable name. More generally, the language designer must specify how to recognise each terminal symbol as some substring of the input. This is called the lexical structure of the language, and for Microbrew it is as follows:

The definition keyword, terminal symbol def, is just the substring “def”.
A variable, terminal symbol var, is any substring consisting of letters or digits and starting with a lowercase letter, except the substring “def”.
An identifier, terminal symbol ident, is any sequence of letters or digits starting with an upper-case letter.
The terminal symbols for left parenthesis, right parenthesis, comma, and equals are just substrings consisting of exactly those characters.

Sometimes a programming language will just describe the lexical structure informally, as I have done here for Microbrew, see also Python. Many languages use a separate grammar to present the lexical structure, e.g. Rust, OCaml, Java. However it is described, there is usually an implicit rule that each mention of “substring” in the description really means “maximal substring”. That is, if we have a C program substring like “fortitude” then this must be an identifier and not the keyword “for” followed by an identifier “titude”. This implicit rule is called maximal munch.

The Microbrew Frontend

The Microbrew interpreter is a tool for reading Microbrew code line-by-line and executing it. The problem sheet this week will involve you implementing your own version of a part of it.

The interpreter has four components, the lexer, the parser, the evaluator and the printer. You can see an example of the data flow through the interpreter below.

The input to the interpreter is some code in textual form, i.e. a string. The output is also a string - if the input string described an expression, then the output string will be the value resulting from evaluating that expression.

The lexer, parser, evaluator and printer implement the processing from input to output. In this part of the unit we are interested in syntax, so we will only look in detail at the first two components. Together these components, the lexer and the parser, form the frontend of the interpreter.

The Lexer

Input: Program text given as a string of characters.
Output: Sequence of tokens.

Conceptually, the lexer is responsible for taking the input string of characters and turning it into a string of terminal symbols, according the lexical structure of the language.

If our only goal for the frontend was to check whether a given input string was a valid Microbrew program, and this will be your only goal in the week 3 problem sheet, then this would be enough. However, to have a working interpreter, whenever the input string is a valid Microbrew program, we want to construct an in-memory representation of its structure so that we can then evaluate (execute) it.

To build this structured representation of the program, we can’t afford to simply forget the names of variables and identifiers- if we want to evaluate the program, it really is important to know which identifier occurs at a particular program point and not only that it is an identifier. So, in reality, the lexer actually produces a string of terminal symbols that is annotated with the original variable and identifier names. This combination of a terminal symbol optionally annotated with some substring of the program text (e.g. a variable name) is called a token, and the optional substring component is called a lexeme.

You can see in the picture above that the lexer has recognised that the first three characters constitute an identifier, so the first token in the output is the terminal symbol ident annotated with the substring Add. The fourth character in the input string is a left parenthesis and so the next token in the output sequence is the left parenthesis terminal symbol (here it is not useful to annotate it with a lexeme). The fifth character of the input was another identifier with name “S”, and so the next token output is the terminal symbol ident annotated with the substring S; and so on.

Incidentally, you can see from character 12 of the input string that the lexer makes good on our assumption that whitespace is not relevant when giving the grammar for a programming language. In most programming languages whitespace is essential in the original program text - the input string - to separate different entities: imagine some C code like intx=3; which has the whitespace stripped away, we don’t know if it is meant to be int x = 3; or intx = 3; (the assignment of three to the variable called intx). However, our grammars have so far all assumed that whitespace is irrelevant, the input is just a sequence of terminal symbols. The lexer bridges this gap, it uses whitespace in the input string to help recognise where one terminal symbol ends and another begins, but it also strips it away - once we have converted the input string to a sequence of tokens, whitespace is no longer useful.

The Parser

Input: Sequence of tokens.
Output: Abstract syntax tree.

The parser is responsible for taking the sequence of tokens and recognising the higher-level, grammatical structure of the programming language, according to the language grammar. There are two aspects to the parser:

It is responsible for checking that the given list of terminal symbols describes a valid Microbrew program. For this, the parser only requires the sequence of terminal symbols but not their annotatations (the lexemes). The particular names of variables and identifiers are not necessary (since they are anyway indistinguishable in the grammar).
Whenever the string of terminals is a valid program, it outputs a tree representation of the structure of that program, which will be passed along to the evaluator component to be executed. For this, the parser does require the particular names of variables and identifiers (the lexemes), because whether you are calling function F or function G is important when evaluating the program.

In the picture above you can see a tree representation of the structure of the program. We will discuss this in more detail later, but the idea is that the tree shows you that, at its root, the expression that was described by the input string is actually a call - we use the node label App which is traditional in programming language theory and stands for “function APPlied to some arguments” or simply “function APPlication”. Then the children of the each App node describe the key components of the function call: the subtree in the left-most child is the function that is being applied (called), all children to the right of it constitute the arguments of that function. So, in this example, we can see that the first argument to the call to Add, i.e. the middle child of the root, is itself a call to S, and the argument to this call to S is itself a call to Z, and so on.

These kinds of trees are called abstract syntax trees or ASTs for short. We will discuss them in more detail in a later lecture, but for now I hope it’s clear that:

It’s a tree structure
It’s still just a representation of the syntax of the program: there is nothing in the tree that explains what happens when you make a call to Add (semantics), only where the call occurs and what its arguments are.
The tree representation is, in a sense, more abstract than the string version of the program code because we have forgotten certain syntactic details like whitespace and superfluous bracketing. For example, the strings Add(S(Z()),S(Z())) and (Add(((S (Z()))), S(Z()))) will both result in the same abstract syntax tree (which is the one picured).

Implementation of the Lexer

The Microbrew interpreter happens to be written in OCaml, which is an impure functional programming language. The qualifier impure means that functions do not only return a value, like in Haskell, but can have other side effects such as mutating local state, opening file handles, throwing exceptions and so on. We’re not going to learn OCaml in these lectures, rather we’re just going to see it as a kind of psuedocode to describe the behaviour of the interpreter.

Since it is a functional programming language, the most natural way to represent tokens is with an algebraic datatype (also called a variant type in OCaml). The following piece of OCaml defines a datatype called token which has seven constructors.

type token =
  | TkIdent of string
  | TkVar of string
  | TkLParen
  | TkRParen
  | TkDefine
  | TkComma
  | TkEquals

Each of the constructors corresponds to one of the terminal symbols, and those terminal symbols that require an annotation have a string argument. For example, the token that consists of the terminal symbol for the left parenthesis is represented simply as TkLParen, this is a value of type token. The token that consists of terminal symbol ident annotated with the string “Add” is encoded by the value TkIdent "Add".

Now that we have a type for tokens, our objective is to implement the lexer as a function lex : string -> token list. I.e. that takes a string as input and transforms it into a list of tokens as output.

Input and Output State

This idea of this lex function is as follows. It will proceed character by character through the input string, consuming each character in turn and outputing a token whenever a complete terminal symbol is recognised.

The implementation is in an imperative style, with the input string and progress through it tracked by some internal state. To avoid dependence on the particular choice of representation for this internal state, there is a small API which is used by the rest of the lexer:

peek () returns Some c when c is the current character of the input, and None otherwise.
drop () discards the current character from the input.
emit tk adds the token tk to the end of the output token sequence.

State Machine Architecture

Some consideration of the lexical structure of the language leads to the following observation. There are some characters where the lexer can immediately output the corresponding token (terminal symbol + optional lexeme), irrespective of which characters have been seen so far, and there are some characters where the lexer needs more context in order to know what to do.

For example, when encountering the left parenthesis character '(' in the input string the lexer can immediately output the token TkLParen into the output list, no matter which characters have been seen before it. Similarly, when encountering the equals character '=' in the input string, the lexer can immediately output the token TkEquals.

However, when encountering the character 'e' the lexer cannot know how to proceed without more information. This ‘e’ could be part of a identifier MkTree, or part of a variable me, or part of a keyword def. So here, the lexer needs to know that it is in the middle of reading in a variable, identifier or keyword (though it does not necessarily yet know which), and remember the relevant sequence of characters that came before it. It can’t take action - that is output a token - until it has reached the end of the identifier, variable or keyword.

This leads to a state machine style architecture in which there are two states:

The “initial” state, in which there is no need to remember anything.
The “identifier, variable or keyword” state, in which the lexer knows that it is in the middle of scanning either an identifier, variable or keyword, and so should remember the constituent characters in some variable in order to create the lexeme once it determines which it is.

The lexer begins in the “initial” state. In this state, reading in a left parenthesis, right parenthesis, comma or equals character takes the lexer back to the “initial” state and outputs the corresponding terminal symbol as a side effect. The lexer switches from the “initial state” to the “identifier, variable, or keyword” state upon reading a lower or uppercase letter. It stays in the “identifier, variable or keyword” state so long as the next character is a lower or uppercase letter or a number. It switches back to the “initial” state when the next character is not a letter or a digit, because this signals that it has finished reading the identifier, variable or keyword.

We implement these states as two recursive functions lex_init : unit -> unit and lex_var_or_id_or_kw : unit -> unit. The idea is that whilst the lexer is executing a call to one of these functions, one can think of it as being “in” the corresponding state. Here is the code for lex_init:

let rec lex_init () =
  match peek () with
  | None ->
      (* We already processed the whole input *)
      emit TkEnd
  | Some '(' ->
      drop ();
      emit TkLParen;
      lex_init ()
  | Some ')' ->
      drop ();
      emit TkRParen;
      lex_init ()
  | Some '=' ->
      drop ();
      emit TkEquals;
      lex_init ()
  | Some ',' ->
      drop ();
      emit TkComma;
      lex_init ()
  | Some c when is_wspace c ->
      drop ();
      lex_init ()
  | Some c when is_letter c ->
      (* Move to lexer state var_or_id_or_kw with a so far empty lexeme *)
      lex_var_or_id_or_kw ("")
  | _ -> raise_lex_error "valid character"

Hopefully the algorithm is quite clear. On entry to this function, we first peek at the next character of the input and try to match it against one of a number of predefined patterns. In case there is no more input string to process (i.e. we already reached the end of the string), peek () will return None and we will emit the end-of-input token TkEnd and return from the function. If there is a character still to process, and it is a left parenthesis, we will drop it from the input string (i.e. advance the cursor to the next character of the input), emit the TkLParen token and then return to the initial state ready to process the next character. This last part is implemented by making a recursive call to lex_init (). Similar remarks apply if the next character is ), = or ,. If the next character is whitespace, we can simply drop it and continue in the same state. If the next character is a lower or uppercase letter, then we are starting to scan a variable, identifier or keyword and so we will move to the second state. Finally, if we see any other character, the input cannot possibly be a valid Microbrew program, and so we throw an exception.

The second state is implemented by the (mutually) recursive function `lex_var_or_kw_or_id

and lex_var_or_id_or_kw (lexeme: string) =
  match peek () with
  | Some c when is_letter c ->
      drop ();
      (* Return to this same state *)
      lex_var_or_id_or_kw (lexeme ^ String.make 1 c)
  | _ ->
      (* We have reached the end of the lexeme,
        Check if it is the keyword "def",
        otherwise it's a variable or identifier. *)
      (match lexeme with
      | "def" -> emit TkDefine
      | _     ->
          (* Determine if it is a variable or identifier *)
          if is_lower (lexeme.[0]) then
            emit (TkVar lexeme)
          else
            emit (TkIdent lexeme)
      );
      (* Continue in the initial lexer state *)
      lex_init ()

In this state, we are scanning a variable, identifier or keyword, and, because in the two former cases we want to preserve the actual name (the lexeme), we need to keep track of it. This will also help us to decide which of a variable, identifier or lexeme it is that we are scanning. We keep track of the lexeme in the argument of the function. The idea is that when the machine is executing a call lex_var_or_id_or_kw ("foo") then this means the lexer is in the “variable, identifier or keyword” state and so far we have seen the string foo.

The overall shape is similar: we start by peeking at the next character of the input. If it is another letter (i.e. the proper continuation of a variable, identifier or keyword), then we drop it and add it to the current lexeme, returning to the same state. Otherwise, we must have come to the end of the variable, identifier or keyword, and it is time to decide which of those we actually have in our hand (in the lexeme parameter). If lexeme is exactly the string "def", then we have scanned the define keyword and so we emit the token TkDefine. Otherwise, we have a variable or an identifier, and these can be distinguished by whether their first character is lower or uppercase. Finally, we return to the initial state.

Lexer Interface

Finally, the lex function simply takes the input string, sets up the internal state variables and begins lexing in the initial state.

let lex (s:string) : token list =
  (* Setup the internal variables *)
  input := s;
  idx := 0;
  output := [];
  (* Begin lexing in the initial state *)
  lex_init ();
  (* Return the output *)
  !output
